Mondraker Prime

Rahmen

Prime Xtralite 6061 Full Butted Alloy, Forward Geometry, intenal removable battery, tapered head tube, Boost 12x148mm rear axle, integrated dropout speed sensor

Steuersatz

Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

Gabel

RockShox Recon Silver RL 29, 120mm, Motion control, Solo Air, tapered steerer tube, Boost 15x110mm axle, 32mm steel stanchions, 42mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload

Antrieb

Bosch Performance Line CX Cruise (25Km/h) GEN4 SMART SYSTEM

Akku

Bosch Powertube 625Wh

Display

Bosch Intuvia 100 / Bosch Mini Remote / Bosch System Controller

Felge

Mavic E-CrossRide 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes

Naben

VR: Mavic, Boost 15x110mm, IS 6 bolts | HR: Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts, HG freehub

Reifen

Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead

Laufradgröße

29"

Schaltwerk

SRAM SX Eagle, Roller Bearing Clutch Typ 3, Cage Lock, langer Käfig, 1x12-fach, X-Actuation 1:1

Schalthebel

Sram Trigger SX Eagle, 12s, X-Actuation 1:1, single click

Kette

Sram SX Eagle, 12s, Powerlock

Kurbel

Race Face Aeffect ebike, 165mm

Kassette

Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1

Bremsen

VR: Sram Level T, 2 piece caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pad | HR: Sram Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad

Lenker

Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore

Griffe

Onoff Twin, 1lock-on, 135mm

Vorbau

Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore

Sattel

MDK ebike black

Sattelstütze

Onoff Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 31.6mm, length 400mm

Pedale

Nicht im Lieferumfang enthalten
